FireNEX™-5000H+ is the latest USB SuperSpeed optical fiber extension solution from Newnex. In addition to the capability of extending USB SuperSpeed 5Gbps data up to 300 meters via an optic fiber cable, FireNEX™-5000H+ can also support USB 2.0/1.1 lower speed peripherals which are still widely used.
FireNEX™-5000H+ contains one Local Unit for connection to the host computer and one Remote Unit with two stacked USB Type-A Downstream Ports for device connections. The USB ports on both Local and Remote Unit are all featured with USB3 Vision standard compliant locking port to ensure interconnections with cables are secure.
In the Box
- 1x FIRENEX™-5000H+ Local Unit
- 1x FIRENEX™-5000H+ Remote Unit
- 1x 12V DC Power Adapter (US)
- 1x USB A to B Host Cable, 1m
- 1x FIRENEX™-5000H+ User Manual
- 100% Plug and Play
- Support 5Gbps SuperSpeed USB 3.1 Gen 1
- USB 2.0/1.1 Backward Compatible with Windows OS
- Extension Distance up to 300 meters
- Compact Size and Light Weight
- Durable Metal Enclosure
- AIA USB3 Vision® Compliant Locking Port
- RoHS Compliant
Q: What is the maximum length that the FireNEX™-5000H+ can support?
A: The current model of the FireNEX™-5000H+ can support a length of up to 300 meters with an OM3 or OM4 fiber cable.
Q: Is FireNEX™-5000H+ backward compatible with USB 2.0/1.1 devices such as a keyboard or a mouse?
A: Yes, FireNEX™-5000H+ is backward compatible with USB 2.0/1.1 peripherals on Windows OS.
Q: Can FireNEX™-5000H+ work on Linux and Mac OS?
A: Yes, FireNEX™-5000H+ supports USB 3.0 data transfer only on Linux and Mac OS. If you need USB 2.0/1.1 support please choose another product, FireNEX™-5000Plus, from Newnex.
Q: Can I use FireNEX™-5000H+ with single-mode fiber?
A: By default, FireNEX™-5000H+ needs to use with a multi-mode fiber.If it is used with a single-mode fiber, please contact Newnex for special order.
Q: Are there any drivers required for FireNEX™-5000H+ to work?
A: No, FireNEX™-5000H+ does not require any additional driver to operate.
Q: Where can I find the RoHS Certificates for FireNEX™-5000H+?
A: Visit https://www.newnex.com/compliance.php for the RoHS information of Newnex products.
